ATEN SXP-500 High-Speed Bi-Directional Converter
Couldn't load pickup availability
Regular price
$249.95 USD
Share this product!
The SXP-500 and SXP-550 are more powerful versions of the SXP-320 and SXP-325. They carry over many of the same features found on the SXP-320 and SXP-325 pair - such as DIP switch for data flow direction, hardware handshake, and XON-XOFF software handshake, but have been greatly enhanced by means of ASIC implementation design; a sixteen mode selectable baud rate from 300 to 460800 bps; and a parallel buffer speed of 2 MB per second (maximum).
- Non Powered (SXP-500)
- Compact Size
- 300 - 460800 bps Baud Rate
- DIP Switch for Direction Setting
- Built In Buffer for Efficient Operation (SXP-550)
- 2 MB/Sec (Max) Parallel Buffer Speed (SXP-550)
- Auto Data Compression up to 15~85%
| Function | SXP-500 | SXP-550 | |||||
| Connectors | Serial | RS-232, DB-9 Female Centronics | |||||
| DB-25 Female | |||||||
| Parallel | |||||||
| Data Direction | Bidirectional | ||||||
| Serial Mode | DCE only | ||||||
| Buffer Speed | N/A | 2 MB/Sec (Max) | |||||
| Memory | N/A | 512 KBytes | |||||
| Baud Rate | 16 Mode, 300-460800 bps | ||||||
| Data Compression | 15-85% | ||||||
| Handshake | Hardware or XON-XOFF | ||||||
| LEDs | Slow Down, Data In, Error, Ready | ||||||
| Function Keys | Reset | ||||||
| Power Consumption | DC 9V 150mA (Max) | ||||||
| Case | Plastic | ||||||
| Weight | 100g | ||||||
| Dimensions (L x W x H) | 101 x 62 x 25 mm | ||||||
